Hex Collar Bolts/ Collared Hex Bolt
SS Flat Head Collar Hex Bolt, Duplex Threaded Collar Bolt, Super Duplex Steel Concrete Hex Collar Head Bolt, Steel Collar Hex Galvanized Bolts, 12mm High Tensile Coach Collar Hex Bolts, M3-M20 Alloy Steel Collar Hex Head Screws, Nickel Alloy Heavy Hex Collar Bolts, SS Collar Hex Bolts Price List, Titanium Collared head coach Bolts at Best Price in India.
Ranfit Metals are one of the leading manufacturer, supplier and exporter of high quality carbon steel, alloy steel, duplex steel, high nickel alloy, inconel, monel, hastelloy, alloy 20, copper nickel, titanium, brass, stainless steel Collared Hex Bolts, ss hexaonal Bolt, forged heavy hexaon Bolt High Tensile Steel Hex Bolts, heavy hex Bolt in Mumbai, India.
Known for their resistance against corrosion, seamless finish, dimensional accuracy and sturdy construction, these ss fasteners Collar Hex Bolt products are available with us in various dimensions, grades and sizes. Owing to unbeatable performance, high quality and highly durable nature, these stainless steel fasteners products are highly demanded in the national and international market.
Metal Bolts and High Tensile Collar Hex Bolt can be avail in various sizes, grade and materials of duplex steel, incoloy, hastelloy, alloy steel, copper nickel, stainless steel, super duplex steel, inconel, monel, titanium, carbon steel, brass alloys, gun metal, bronze alloys, etc. As mention below:
SS Hexagon Head Bolt Price, Buy Stainless Steel Hexagonal Bolt, M20Inconel Collar Heavy Bolt Exporter, M33 Monel Collar Head Bolt, Hastelloy Flange Collar Hex Bolts, High Quality Collar Hex Bolt Dealer, M3 Incoloy Stud Collar Hex Bolt, Brass Forged Hex Collar Bolts, Cupro Nickel Collar Hex Bolt Sizes, SSHeavy Collar Hex Bolts Supplier In Mumbai, India.
Collar Hex Specification
| Standards of Collar Hex Bolts | DIN, ASTM, BS and all International Standards |
| Collar Hex Size | M3 - M56 | 3/6" to 2" | Custom Sizes |
| Heavy Collar Hex Length | 3 mm to 200 mm |
| Collar Hex Bolt Surface Coating |
Teflon Coating Cadmium Coating Xylon Coating Zinc Coating Ptfe Coated Bolts Phosphate Coating Hot Dipped Galvanizing Coating |
| Concrete Collar Hex Bolts finishing | Coatings & Finishes : Hot Dip Galvanised (HDG), Self-Colour, Passivated, Bright Zinc Plated (BZP), Sherardized, Dacroment, nickel plated, some special one like DACROMET Geometry and Mechanically Applied coating, anodizing, plated zinc-nickel Zinc (blue, black, yellow, white), black oxide, |
| Types Of Collar Hex Bolt | Collar Hex Bolt, Heavy Hex Bolt, M12 Collar Hex Bolt, Flange Collar Hex Bolt, Collar Hex Anchor Bolts, Collar Hex Lag Bolt. |
| Die forging Collar Hex Bolts | Closed die forging, Open die forging, and Hand forging. |
| Threads Collar Hex Bolt | BSW, UNC, UNF, BSF, Metric, and as per costumers required. |
| Stainless Steel Collar Hex Bolts | AISI 316, 316L, 304L, 321, 347, 317L, 302, 304, 310, 317, 410, 420, 904L etc. |
| Alloy Steel Collar Hex Bolts | ASTM / ASME A/SA 193 / 194 B 6, B 7/ B 7M, B 16, 2, 2HM, 2H, GR 6, B 7, B 7M |
| Carbon Steel Collar Hex Bolts | ASTM A307, A193 |
| Duplex & Super Duplex Steel Collar Hex Bolts | ASTM / ASME A815 UNS No. S31803, UNS No. S 32205, UNS No. S 31254, UNS No. S 31550, UNS No. S 32750, and UNS No. S 32760 |
| Nickel Alloy Collar Hex Bolts | ASTM / ASME SB 160 / 164 / 425 / 166 / 446 / 574 / 472 UNS 2200 (NICKEL 200) / UNS 2201 (NICKEL 201), UNS 8825 (INCONEL 825), UNS 6625 (INCONEL 625), UNS 6600 (INCONEL 600) / UNS 6601 (INCONEL 601), UNS 4400 (MONEL 400), UNS 10276 (HASTELLOY C 276), UNS 8020 (ALLOY 20 / 20 CB 3) |
| Application of Collar Hex Head Bolt |
|
Dimensional Chart Of SS Collar Hex Bolts
| Nominal Screw Diameter ; Thread Pitch | D | S | K | R | B Thread Length | F | |||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Body Diameter | Width Acress Flats | Head Height | Fillet Radius Min. | ; | For L ; 125 ≤ 200 | For L ≤ 125 | Longest Stand. Bolt Length Thd. to Head | ||||
| Min. | Max. | Min. | Max. | Min. | Max. | ||||||
| M12 x 1.75 | 11.73 | 12.00 | 17.73 | 18.00 | 7.24 | 7.76 | 0.6 | ; | 36 | 30 | 40 |
| M14 x 2 | 13.73 | 14.00 | 20.67 | 21.00 | 8.51 | 9.09 | 0.6 | ; | 40 | 34 | 45 |
| M6 x 1 | 5.82 | 6.00 | 9.78 | 10.00 | 3.85 | 4.15 | 0.3 | ; | 24 | 18 | 25 |
| M8 x 1.25 | 7.78 | 8.00 | 12.73 | 13.00 | 5.10 | 5.50 | 0.4 | ; | 28 | 22 | 30 |
| M10 x 1.5 | 9.78 | 10.00 | 15.73 | 16.00 | 6.17 | 6.63 | 0.4 | ; | 32 | 26 | 35 |
| M24 x 3 | 23.67 | 24.00 | 35.00 | 36.00 | 14.56 | 15.44 | 0.8 | ; | 60 | 54 | 75 |
| M16 x 2 | 15.73 | 16.00 | 23.67 | 24.00 | 9.68 | 10.32 | 0.6 | ; | 44 | 38 | 50 |
| M20 x 2.5 | 19.67 | 20.00 | 29.16 | 30.00 | 12.12 | 12.88 | 0.8 | ; | 52 | 46 | 60 |
| M30 x 3.5 | 29.67 | 30.00 | 45.00 | 46.00 | 17.92 | 19.48 | 1.0 | ; | 72 | 66 | 90 |
Equivalent Grade of SS Hex Collar Bolt
| Grade | Country | 310 | 304 L | 304 | 316 L | 316 | 410 |
|---|---|---|---|---|---|---|---|
| UNS | North America | S31000 | S30403 | S30400 | S31603 | S31600 | S41000 |
| DIN | German | X 12 CrNi 25 21 | X 2CrNi1911 | X 5CrNi1810 | X 2 CrNiMo 17 13 2 | X 5 CrNiMo 17 13 2 | X 10Cr13 |
| BS | British | BS 970 | BS 970 | BS 970 | BS 970 | BS 970 | BS 970 |
| ASTM | America | ASTM A 479 | ASTM A 320 Ge B8 | ASTM A 193 Gr B8 | ASTM A 320 Ge B8M | ASTM A 193 Gr B8M | |
| EN | European | 1.4841 | 1.4306 | 1.4301 | 1.4404 | 1.4401 | 1.4006 |
Types of Bolts
Foundation Collared Hex Bolts Forms & Availability
| Products | Size | |
|---|---|---|
| SS Collar Hex Flat Head Bolts | Stainless Steel Collar Hex Head Bolts | M 02 to M 160, Custom Sizes |
| Cu-Ni Galvanized Hex Collar Bolts | Carbon Steel Threaded Collar Hex Bolt | |
| Incoloy Collar Head Bolt | Titanium Flat Head Collar Hex Bolts | |
| SMO 254 Fully Threaded Collar Hex Head Bolts | Titanium Collar Hex Decorative Concrete | |
| Inconel Collar Hex knurled-neck Bolt | NickelConcrete Collar Hex Bolts | |
| Hastelloy Collar Head Bolt | Monel High Tensile Collar Hex Bolts | |
| Alloy 20 Hex Collar Bolt | Alloy Steel Collar Head Coach Bolts | |
Other Types of Collar Head Bolt
| ASTM A182 F304L Collar Head Bolt | ASTM A350 LF2 Flange Hexagonal Mild Steel Collar Hex Bolt, |
| M3 to M100 M16 Black Coated Collar Hex Bolt | Ss Heavy Collar Hex Bolts |
| Alloy Steel M12 Hex Collar Bolt Supplier | 316L Stainless Steel Collar Hex Head Bolt |
| Stainless Steel Collar Manufacturer | Cupro Nickel Flange Collar Hex Head BoltsDealer |
| SS Collar Hex Bolt Size | MonelCollared Hex Head Lag Bolts |
| SS Collar Head Bolt Size Chart | Ss Collar Hex Bolt price |
| Ss Threaded T Collar Hex Head Bolt types | Ss 4-Sided Collar Hex Head Bolts price |
| Monel 400 Collar Bolts | Inconel 600 Collar Threaded Bolt Stockists |
| ASTM A105 M16 Hex Collar Bolt | Inconel F5 Collar Head Bolt |
| High Strength High Tensile Collar Hex knurled-neck Bolts | UNS K41545 Concrete Custom Collar Hex Flat Head Bolts |
| Stainless Steel Collar Bolts | Nickel 200 Collar Hex Decorative Bolts |
| High Nickel Foundation Collar Hex Head Bolts | UNS S30400 Collar Anchor Bolts |
| Ss Custom Collar Head Bolt sizes | SS Collar Hex knurled-neck hsn code |
| Stainless Steel M12 Collar Hex Bolt | Alloy Steel Collar Hex Anchor Bolts Supplier |
| Hastelloy C22 Collar Hex Head Bolts | 317L SS Hex Collar Industrial Bolts |
